Glass to Glass Hydraulic Hinge - 8015 Biloba

Colcom Oildynamic 8015 self closing hinge (SSS)

This versatile brass hinge is suitable for both residential and commercial settings. It features superior corrosion-resistant plating and a 90 degree opening from the wall to glass, making it ideal for shower doors with a thickness of 8-12mm and a weight capacity of up to 54KG. This product, BL 8015 with central fixing, is designed specifically for double action residential glass doors, providing a secure and functional experience. It also includes a hydraulic hinge, allows for closing speed adjustment, and features a hold open function at + 90° and - 90°. It can even be used for single action doors, offering a versatile solution for a range of internal glass doors.

Please Note:

Opening further than 95° could unhinge the door. We suggest to install a door stop.

The angle for the start of self-closing can vary by +/- 5° depending on external factors and the door format in the usual fields of application.

For doors with width less than 500 mm (19.685") use items BL 8015 + BL 8015 SOL.

Cover caps in matt stainless steel and polished stainless steel available on request.
